OSSEC是一款開源的多平臺的入侵檢測系統，可以運行于Windows, Linux, OpenBSD/FreeBSD, 以及 MacOS等操作系統中。包括了日志分析，全面檢測，root-kit檢測。
1. 測試和驗證OSSEC泛化及告警規則
OSSEC默認具有一個ossec-logtest工具用于測試OSSEC的泛化及告警規則。該工具一般默認安裝于目錄 /var/ossec/bin 中。
使用示例：
/var/ossec/bin/ossec-logtest 2014/06/1113:15:36 ossec-testrule: INFO: Reading local decoder file. 2014/06/11 13:15:36 ossec-testrule: INFO: Started (pid: 26740). ossec-testrule: Type one log per line. Jun 10 21:29:33 172.16.25.122/172.16.24.32 sshd[24668]: Accepted publickey for root from 172.16.24.121 port 38720 ssh2 **Phase 1: Completed pre-decoding. full event: 'Jun 10 21:29:33 172.16.25.122/172.16.24.32 sshd[24668]: Accepted publickey for root from 172.16.24.121 port 38720 ssh2' hostname: '172.16.25.122/172.16.24.32' program_name: 'sshd' log: 'Accepted publickey for root from 172.16.24.121 port 38720 ssh2' **Phase 2: Completed decoding. decoder: 'sshd' dstuser: 'root' srcip: '172.16.24.121' **Phase 3: Completed filtering (rules). Rule id: '10100' Level: '4' Description: 'First time user logged in.' **Alert to be generated.
如上文所示，當輸入日志內容：
Jun 1021:29:33 172.16.25.122/172.16.24.32 sshd[24668]: Accepted publickey for rootfrom 172.16.24.121 port 38720 ssh2
該條日志經過三步處理，生成了一條4級告警，規則ID為10100，內容為“First time user logged in.”
使用ossec-logtest–v命令，可獲取更詳細的日志分析邏輯。
/var/ossec/bin/ossec-logtest -v 2014/06/11 13:44:52 ossec-testrule: INFO: Reading local decoder file. 2014/06/11 13:44:52 ossec-testrule: INFO: Started (pid: 27091). ossec-testrule: Type one log per line. Jun 11 21:44:41 172.16.25.122/172.16.24.32 sshd[27743]: Did not receive identification string from 172.16.24.121 **Phase 1: Completed pre-decoding. full event: 'Jun 11 21:44:41 172.16.25.122/172.16.24.32 sshd[27743]: Did not receive identification string from 172.16.24.121' hostname: '172.16.25.122/172.16.24.32' program_name: 'sshd' log: 'Did not receive identification string from 172.16.24.121' **Phase 2: Completed decoding. decoder: 'sshd' srcip: '172.16.24.121' **Rule debugging: Trying rule: 1 - Generic template for all syslog rules. *Rule 1 matched. *Trying child rules. Trying rule: 5500 - Grouping of the pam_unix rules. Trying rule: 5700 - SSHD messages grouped. *Rule 5700 matched. *Trying child rules. Trying rule: 5709 - Useless SSHD message without an user/ip and context. Trying rule: 5711 - Useless/Duplicated SSHD message without a user/ip. Trying rule: 5721 - System disconnected from sshd. Trying rule: 5722 - ssh connection closed. Trying rule: 5723 - SSHD key error. Trying rule: 5724 - SSHD key error. Trying rule: 5725 - Host ungracefully disconnected. Trying rule: 5727 - Attempt to start sshd when something already bound to the port. Trying rule: 5729 - Debug message. Trying rule: 5732 - Possible port forwarding failure. Trying rule: 5733 - User entered incorrect password. Trying rule: 5734 - sshd could not load one or more host keys. Trying rule: 5735 - Failed write due to one host disappearing. Trying rule: 5736 - Connection reset or aborted. Trying rule: 5707 - OpenSSH challenge-response exploit. Trying rule: 5701 - Possible attack on the ssh server (or version gathering). Trying rule: 5706 - SSH insecure connection attempt (scan). *Rule 5706 matched. **Phase 3: Completed filtering (rules). Rule id: '5706' Level: '6' Description: 'SSH insecure connection attempt (scan).' **Alert to be generated.
2. 自定義日志泛化規則
2.1 添加日志源
添加日志源的方式很簡單，通過修改/var/ossec/etc/ossec.conf 即可實現。
如果日志源是本地文件，可通過添加如下配置實現。
如果日志源是遠程syslog，可通過添加如下配置實現。
2.2 創建自定義的日志泛化規則
假如有兩條日志如下文：
Jun 11 22:06:30172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat loginSUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .Jun 11 22:06:30172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login PWD_ERRORfrom 172.17.153.36 to 172.17.153.38 distport 3333 .
該日志使用ossec-logtest分析之后結果如下：
Jun 11 22:06:30 172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .**Phase 1: Completed pre-decoding. full event: 'Jun 11 22:06:30 172.16.25.130/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .' hostname: '172.17.153.38/172.16.24.32' program_name: '/usr/bin/auditServerd' log: 'User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .'**Phase 2: Completed decoding. No decoder matched
由此可知OSSEC在分析日志的時候，經過了兩個泛化過程：pre-decoding和 decoding。
pre-decoding過程是ossec內置的，只要是標準的syslog日志，都可以解析出如下4個基本信息。
Timestamp:Jun 11 22:06:30Hostname: 172.17.153.38/172.16.24.32Programe_name: /usr/bin/auditServerdLog: User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333.
在decoding過程，用戶可以通過修改/var/ossec/etc/decoder.xml，實現自定義的泛化。例如在該文件中添加如下規則：
再次執行/var/ossec/bin/ossec-logtest
**Phase 1: Completed pre-decoding. full event: 'Jun 11 22:06:30 172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .' hostname: '172.17.153.38/172.16.24.32' program_name: '/usr/bin/auditServerd' log: 'User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .' **Phase 2: Completed decoding. decoder: 'auditServerd'
發現，該條日志成功命中了名為auditServerd的規則，該條規則可以準確的將日志定位為是程序auditServerd所發出的。
除此之外，基于auditServerd這條規則，我們還可以添加更多的子規則，來識別出更多的信息。如:
再次執行/var/ossec/bin/ossec-logtest，可獲取更多的信息，如下：
**Phase 1: Completed pre-decoding. full event: 'Jun 11 22:06:30 172.17.153.38/172.16.24.32/usr/bin/auditServerd[25649]: User blackrat login SUCEESS from 172.17.153.36 to172.17.153.38 distport 3333 .' hostname: '172.17.153.38/172.16.24.32' program_name: '/usr/bin/auditServerd' log: 'User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38distport 3333 .' **Phase 2: Completed decoding. decoder: 'auditServerd' dstuser: 'blackrat' status:'SUCEESS' srcip: '172.17.153.36' dstip: '172.17.153.
用戶通過配置上述正則表達式，獲取特定字段，用于后續的關聯分析。OSSEC一共內置了14個用戶可解析的字段：
- location – where the log came from (only on FTS) - srcuser - extracts the source username - dstuser - extracts the destination (target) username - user – an alias to dstuser (only one of the two can be used) - srcip - source ip - dstip - dst ip - srcport - source port - dstport - destination port - protocol – protocol - id – event id - url - url of the event - action – event action (deny, drop, accept, etc) - status – event status (success, failure, etc) - extra_data – Any extra data
3. 自定義日志告警規則
3.1 規則文件路徑配置
OSSEC的規則配置文件默認路徑為/var/ossec/rules/，要加載規則文件，需要在/var/ossec/etc/ossec.conf 中配置，默認的配置如下：
其實通過下列配置，可以實現加載/var/ossec/rules 下的所有規則文件：
于泛化規則，也可以通過配置decoder_dir域來實現，如：
上述配置可將/var/ossec/rules/plugins/plugins/decoders目錄下所有的xml文件都添加為OSSEC日志泛化規則。
對于更詳細的配置及語法，可參考下列文檔：
http://ossec-docs.readthedocs.org/en/latest/syntax/head_ossec_config.rules.html#element-rule_dir
3.2 OSSEC告警規則配置
例如，我們需要增加對程序auditServerd的告警規則，我們需要針對auditServerd程序新建一個規則文件，對于OSSEC中已經存在的規則文件如sshd, openbsd, vsftpd等，我們只需要在對應的文件中進行新增或修改。
首先我們新建文件
/var/ossec/rules/auditServerd_rules.xml
添加如下內容：
上述規則中，規則id 80000 用于對日志進行分組計數，假如日志中出現了泛化為auditServerd的日志，則對該日志分組為auditServer，且狀態機計數加1.
規則80001描述了假如user為blackrat，srcip為172.17.153.36 則命中，并發出“User blackrat is not allowed login from 172.17.153.36!”的告警。
將該文件路徑加入到文件/var/ossec/etc/ossec.conf中
…
執行/var/ossec/bin/ossec-logtest，結果如下：
**Phase 1: Completed pre-decoding. full event: 'Jun 11 22:06:30 172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .' hostname: '172.17.153.38/172.16.24.32' program_name: '/usr/bin/auditServerd' log: 'User blackrat login SUCEESS from 172.17.153.36 to 172.17.153.38 distport 3333 .' **Phase 2: Completed decoding. decoder: 'auditServerd' dstuser: 'blackrat' status: 'SUCEESS' srcip: '172.17.153.36' dstip: '172.17.153.38' dstport: '3333' **Phase 3: Completed filtering (rules). Rule id: '80001' Level: '10' Description: 'User blackrat is not allowed login from 172.17.153.36!' **Alert to be generated.
3.3 關聯分析告警規則
OSSEC可以實現基于因果關系、事件頻次的關聯分析告警，具體實現方式如下。
假如我們想要實現當來自同一IP的用戶登陸auditServerd，在1分鐘內達到5次登錄失敗時，進行告警，我們可以配置規則如下：
執行/var/ossec/bin/ossec-logtest，連續五次輸入日志：
結果如下：
**Phase 1: Completed pre-decoding. full event: 'Jun 11 22:06:30 172.17.153.38/172.16.24.32 /usr/bin/auditServerd[25649]: User blackrat login PWD_ERROR from 172.17.153.36 to 172.17.153.38 distport 3333 .' hostname: '172.17.153.38/172.16.24.32' program_name: '/usr/bin/auditServerd' log: 'User blackrat login PWD_ERROR from 172.17.153.36 to 172.17.153.38 distport 3333 .' **Phase 2: Completed decoding. decoder: 'auditServerd' dstuser: 'blackrat' status: 'PWD_ERROR' srcip: '172.17.153.36' dstip: '172.17.153.38' dstport: '3333' **Phase 3: Completed filtering (rules). Rule id: '80003' Level: '15' Description: 'auditServerd brute force trying to get access to the audit system.' **Alert to be generated.
